Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: YIXI
  • Model Number: YXSP206
  • type: ADSL Splitter ADSL Filter DSL Filter RJ11 with manufacturer prices
  • Output interface: RJ45/RJ11
  • Bandwidth: 4.4MHz
  • Transmission distance: 100m
  • Power voltage: 12V
  • Power frequency: 60KHz
  • Power: 60W
  • Working temperature: -15~85℃
  • material: ABS
  • Gold-plated jack: FU

Packaging & Delivery

Packaging Details outer package: Neutral carton/YIXI carton
Size(mm):380*280*220
QTY(PCS):400
N.W. (KG) :12.0
G.W. (KG):12.5
Delivery Time can be shipped within a week

Specifications

ADSL Splitter ADSL Filter DSL Filter RJ11 with manufacturer prices
1.ISO 9001 and CE
2.Six years producing experience

ADSL Splitter ADSL Filter DSL Filter RJ11 with manufacturer prices







                      ADSL Splitter ADSL Filter DSL Filter RJ11 with manufacturer prices
[Brand] HW-TELECOM
[Model]YXSP206
[Size] 50*36.5*24mm
[Function]
        ADSL Splitter ADSL Filter DSL Filter RJ11 with manufacturer prices  eliminate the interference between data signal and voice signal transmitted in the same telephone line and make the internet and telephone go both at the same time(Data signal for internet voice signal for telephone)
[Market] China, Middle East,Russia and singapore







POST PORT IMPEDANCE Zr=600 Ω
Modem impedance30 kHz to 4.4M Hz100 Ω
Insertion loss@ 1020 Hz<0.3dB
 200 Hz<f<3.4 kHzwith 1020Hz center<± 1 dB
Return loss300 Hz< f< 500 Hz>=14 dB
 500 Hz< f< 2000 Hz>=18 dB
 2000 Hz< f< 3400 Hz>=14 dB
Longitudinal conversion loss LCL50 Hz< f< 600 Hz> =40 dB
 600 Hz< f< 3400 Hz>=46dB
 3400 Hz< f< 30K Hz>=40dB
 30K Hz< f< 1104K Hz>=45dB
 1104K Hz< f< 4.4M Hz>=30 dB
Delay distortion500 Hz<f<2800Hz150 u sec
DC resistance <25 Ω
Isolation resistance, branch-branch100 VDC; term = Ω>5MΩ
Stop band attenuation30 kHz<f<138 kHz>45 dB
 138 kHz<f<4.4 MHz>55dB





















Company Information













Packaging & Shipping









1.Payment

 Payment Terms: L/C,T/T,Western Union

 Bank Details:

 Beneficiary:SHENZHEN YIXI ELECTRONIC CO., LTD Account No:0000 4852 8781 Name of Bank: SHENZHEN RURAL COMMERCIAL BANK CORPORATION LIMITED ADD: NO.3038 COOPERATIVE FINANCE BLDG SHENNAN RD, EAST, SHENZHEN, CHINA SWIFT CODE: SRCCCNBS Western Union: First name:YUESHENG Last name: TANG Country:

 China.



2.Shipping Express:DHL,FedEX,UPS,EMS and TNT Shenzhen Sea Ports:YT,SK,CW,DCW PORT Shenzhen Airport:Bao'an Airport



 3.Packing Details

Package       PE
  Weight  31g
  PCS/CTN  320pcs
  CTN. size  L380mm x W280mm x H220mm
  Gross weight6.9KG
